EAPRO H-1700 Solar PCU Inverter 24V

EAPRO H-1700 Solar PCU Inverter 24V

per piece


Product details

Brand: EAPRO


  • Rated AC power: 1450VA, 24V, Operating Voltage 90-290V
  • Provision for setting of critical parameters as per user requirement, like, Time, Boost Battery Voltage, Solar Max charging current, Battery Low Cut voltage etc
  • Max supported panel power: 24V upto 1600Wp
  • Charge Controller Rating – 50A/24V, with 98% efficiency for fast charging
  • 24 Months Warranty
  • Efficient Current Charging at Low Mains in Normal Mode only.
  • Intelligent Battery Charging and Charge Sharing with Mains/Charging by solar power only.
  • Dual Charging current option for Normal Charging and High Charging
    High Power new generation MOSFET capable of handling high inrush/surge current.
  • Intelligent Multicolor LCD display for all system parameters
  • Programmed inbuilt cooling fan.
  • Inbuilt fully regulated charge controller.
Capacity (VA) 1450VA
Nominal battery voltage (Vdc) 24V
Charge Controller Type PWM
Charge Controller Rating 50A/12V
Maximum PV Power 1600Wp
Rated Output Power (kVA) 1450VA
Input Voltage Range (Voc) 46V
Input Voltage Range (Vmp) 29V -36V
Battery Boost volatage (Adjustable) 14.4V (Default setting)
Battery Low Cut (Adjustable) 10.6V (Default setting)
Grid charging current(Adjustable) 20A (Default setting)
Solar Charging Current(Adjustable) 40A (Default setting)
Dimensions (L*W*H) [mm] 405*370*260 mm (Net Weight 14.96 Kg)
Supported Battery Types Flat,Tubular, VRLA(SMF)



  • Eapro H-1700 is an PWM Solar PCU designed to extract maximum power from Solar Panels to save electricity bills
  • Eapro H-1700 is 1.5kVA 24V Model (requires: 2 x 12V Solar Batteries)
  • We recommend user to choose high efficient solar panels from our Solar Panels section to get maximum output.
  • Please note: installation not included and user need to hire an expert engineer or you can contact UrbanUrja team for arrangements of installation which will be charge extra. All the warranties will be given by EAPRO as per their policies.
  • Solar Hybrid UPS with inbuilt Real Time Clock for providing the optimum performance of the Solar inverter for Maximum Power Saving.
  • Pure Sine wave technology using PWM topology with inbuilt Real Time Clock.
    Smart Solar Selection for maximum utilization of Solar Power.
  • Provision for setting of critical parameters., like, Time, Boost Battery Voltage, Solar Max charging current, Battery Low Cut voltage etc
  • Provision for Setting of 4 different Saving Levels according to the User Requirement including, Full Time Charging from the Solar, No Mains Charging etc.
  • Provision for maintaining the gravity of the battery once in a month.
  • Intelligent Multicolor LCD display for all system parameters
  • Supports dual mode of working, UPS mode (180V to 270V) and Normal mode(90V to 290V)
  • Closed Loop Auto Sensing Software Control(ASSC) Smart Battery Charging Technology for longer battery life.
  • Sine wave output for safety of your sensitive appliances and distortion less operations.
  • Intelligent overload sensing circuitry with auto retrial facility.
