Luminous Solarverter PRO 5kVA Pcu 48V MPPT Solar Inverter

Luminous Solarverter PRO 5kVA Pcu 48V MPPT Solar Inverter



badge
badge
badge

Product details

Solarverter range from Luminous allows smart management of Solar Power, Grid Supply and Battery to deliver uninterrupted power for all electrical applications. Designed for high performance against the typically tough Indian grid conditions, Solarverter PRO is available in 2kVA, 3kVA, 3.5kVA, 5kVA, 6kVA, 7.5kVA & 10kVA options.



Features:

  • Rated AC power - 230V (single phase)
  • Max Supported Panel Power - 5000 Wp, Input Voltage Range (Vmp) – 110V-180V
  • Charge Controller - MPPT, Input Voltage Range (Voc)- 130V-220V
  • Nominal Battery Bank Voltage - 48V (80Ah-220Ah Supported)
  • BIS-certified solar inverter
  • In-built TDR for loads with heavy in-rush current
  • Inbuilt MPPT charge controller to maximize solar generation from solar panels
  • Inbuilt isolation transformer to protect from grid surges and noise
  • User selectable source priority: Choose source priority from solar, battery and grid
  • User-friendly Informative LCD Display
  • MCB protection against short circuit protection
  • Pure sine wave output for better performance & safety of connected loads
  • Safe for your home with comprehensive protection features such as short-circuit, reverse polarity, battery overload, etc.
  • Remote Data Monitoring: Get access to all the data from anywhere on your mobile via the "Connect by Luminous" app and install an (optional) wifi dongle on the back panel

It Supports Lithium Battery & has BMS Communcation Port also on the back panel



Smart Solar Optimization: Gives priority to solar in both backup and charging modes of operation thereby maximizing solar energy utilization

Maximum Power Point Tracking: MPPTs extract up to 30% more power from the panels, minimizing the impact of shading and increasing efficiency.

User-Friendly LCD Display: This makes it convenient for users to easily monitor various performance parameters.

Guaranteed Safety: Comprehensive protection features include short circuits, reverse polarity, surge protection etc.

BIS Certified: BIS certified as per IS/IEC standards

Specifications:

 Model Name Solarverter PRO 5kVA
VA Rating 5kVA
Nominal Battery Voltage (Vdc)  48V
Output Waveform Sinewave
SOLAR PHOTOVOLTAIC INPUT
Type of Charger MPPT
Maximum PV Power (kW) 5000W
Solar Input Voltage (Voc) 130V-220V
Solar Input Voltage Range (Vmp) 110V-180V
Max. PV Input Current (Imp) _A
Nominal Battery Charging Current (At STC) _A±2A
Max. Battery Charging Current (Regulation) ≤_A±10A
No. of MPPT Channels 1
GRID INPUT
Input Supply Phases Single Phase
Input Voltage Mains mode (Regulated UPS Mode) 180-260Vac
Mains Mode (Unregulated UPS Mode) 110-280Vac
Input Protection _A MCB
BATTERY
No. of Batteries 4
Charging Stages Boost, Absorption, Float
Battery Charging Current _A, _A, _A
Type of Battery Tubular/SMF/Flat
UPS
Switching Element MOSFET
Control 16 Bit DSP Controlled
Nominal output Voltage (V) 230V±2%
Output Supply Phase 1 Phase - 3 Wire
Nominal Output Frequency 50 Hz
Nominal Output Current _A
Output Voltage Distortion (THD)
Packaging Comes in Wooden Box
